Keel roll forming machines are an essential piece of equipment for manufacturing industries working with sheet metal. This guide provides a comprehensive overview of keel roll forming machines, their applications, types, specifications, suppliers, installation, operation, maintenance, and more.

Overview of Keel Roll Forming Machines

Keel roll forming machines, also known as channel roll forming machines or C-roll forming machines, are used to form sheet metal into C-shaped channels and structural parts like U-channels.

The key features of keel roll forming machines are:

  • High production efficiency and speed
  • Capability to form complex and customized channel shapes
  • Consistent and high-quality finished products
  • Low operational costs compared to other forming methods

Keel roll forming utilizes a series of consecutive sets of rollers to gradually bend and shape flat sheet metal stock into the desired channel configuration. Adjustable forming rollers accurately control the material flow and deformation during the continuous forming process.

Keel roll forming machines are available in different configurations and specifications to suit the requirements of various industries such as:

станок для формирования килевых валков
Uses of Keel Roll Forming Machines 4

Applications and Uses of Keel Roll Forming Machines

Keel roll forming machines have broad applications across industries:

СтроительствоRoofing, cladding, structural frames, light gauge steel framing
Автомобильная промышленностьChassis, brackets, body panels
AviationAircraft structural parts like stringers and ribs
ЭлектрикаCable trays, enclosures, racks
МебельShelves, storage units, desk frames
ТранспортContainers, trailers, rail coaches

In construction, keel roll forming machines produce C and U-channels for:

  • Light gauge steel load bearing structures
  • Wall studs, roof trusses, solar panel frames
  • Roofing and cladding for industrial buildings
  • Structural columns, beams, and joints

In automotive and aviation, channels formed by these machines provide:

  • Chassis, brackets, and critical structural components
  • Interior panels, running boards, trim parts
  • Stringers, ribs, rails, and frames

For electrical and telecom applications, channels are used in:

  • Cable trays and trunking
  • Server and switch enclosures
  • Equipment racks and cable ladders

Overall, keel roll forming technology enables lean and agile manufacturing across industries compared to press braking or other alternatives.

Types of Keel Roll Forming Machines

Keel roll forming machines are available in different types based on:

1. Production Speed

  • High speed: Up to 120 m/min
  • Medium speed: 60-100 m/min
  • Low speed: Up to 50 m/min

2. Automation Level

  • Manual: Require operators to feed and offload material
  • Semi-automatic: Automatically feeds material, manual offload
  • Fully automatic: Automated material feed and offload

3. Driveline Configuration

  • Direct drive: Each roller has independent motors
  • Chain drive: Rollers linked by transmission chains
  • Central drive: All rollers driven from one main motor

4. Number of Roller Stands

  • 10 stands: For simple C and U channels
  • 16 stands: For complex profiles and hems
  • 18-24 stands: For high strength channels

Selecting the right keel roll forming machine type depends on the production volume, product shape, level of automation, and budget.

Specifications of Keel Roll Forming Machines

The key specifications and parameters to consider for keel roll forming machines are:

Технические характеристикиПодробности
Forming CapacityThickness up to 3mm, width up to 1200mm
Скорость формированияДо 120 м/мин
Размер роликаDiameter 100-150mm, length 400-1000mm
Материал роликаAlloy steel or carbon steel
Приводной механизмIndependent motors, chains, or central drive
Потребляемая мощность18-75 kW range
Система контроляПЛК с сенсорным экраном HMI
РамкаWelded steel frame with base
Размер машины8000-30000mm length, 2500-4000mm width
Вес4000-15000 kg range

The number of roller stands, max strip width, and forming speed determine the production capacity. Construction applications generally require slower speeds but wider widths, compared to automotive parts which require higher speeds but narrower widths.

The roller size, material, and driveline configuration define the forming power. The steel frame provides rigidity during forming. The control system enables setting forming parameters and recipes.

As production requirements go up, higher kW motors, larger rollers, and more roller stands are needed. The machine footprint also increases proportionally.

Keel Roll Forming Machine Suppliers

Some of the leading global suppliers of keel roll forming machines include:

Beijing Jingjiang HuaxiangКитайHigh-end C/U channel and frame forming lines
Ботоу СяньфаКитайRoll forming lines for construction industry
Gasparini S.p.A.ИталияC/U/L section and profile forming machines
ФормтекСШАC, U, Z purlin roll forming machines
Metform InternationalКанадаCustomized roll forming solutions
Самко МашинериВЕЛИКОБРИТАНИЯLight gauge roll forming systems
Shanghai WhitneyКитайHigh-speed cable tray forming lines
Ernst MachineСШАStructural channel forming machines

Ценообразование: Basic keel roll forming machines start around $30,000 and go up to $250,000 for high-end integrated production lines. Cost depends on speed, automation level, features, and customization.

Lead Time: Roll forming equipment is generally built to order with deliveries ranging from 2 to 4 months. Readymade machines may be available for faster delivery.

Customers should evaluate suppliers based on industry experience, local support, machine quality/reliability, and capability to deliver integrated solutions.

станок для формирования килевых валков
Uses of Keel Roll Forming Machines 5

Installing Keel Roll Forming Machines

Proper installation of keel roll forming machines is critical to ensuring forming accuracy, efficiency, and safety. The key steps are:

  • Prepare level concrete foundations as per floor plan drawings
  • Unload machine parts safely using lift truck or crane
  • Assemble frame, ensure squareness using laser alignment
  • Mount roller stands per specified layout
  • Install driveline, motors, and hydraulics
  • Connect electrical, controls, sensors, and safeties
  • Anchor machine securely to foundation
  • Lubricate moving parts and load tooling
  • Verify alignments and clearances
  • Trial run without load, then with material

Sufficient space should be provisioned around the rear and sides of the machine for safe material loading, unloading, and transfer. Utilities like power, compressed air must be adequately sized.

Vibration damping pads can be used underneath the machine to minimize floor vibration. Proper grounding, safety guarding, lighting, ventilation and fire safety systems must also be in place.

Operating Keel Roll Forming Machines

Keel roll forming machine operation involves the following key activities:

1. Safety Checks: Verify all guards in place, no obstacles in machine area, functioning E-stops and safety mats.

2. Machine Warmup: Turn on hydraulics and run machines through warmup cycle without load. Verify smooth operation.

3. Parameter Setting: Input product recipe on HMI screen – part width, thickness, line speed, roller pressures.

4. Tooling Setup: Install correct top and bottom roll tooling as per part profile.

5. Material Loading: Prepare sheet metal coil of the required thickness and load on decoiler. Feed strip through leveler and guides into machine.

6. Trial Run: Jog machine and run sample part to validate tooling setup. Check edge quality and make tooling adjustments if needed.

7. Production Run: Initiate automatic run cycle. Monitor line speed, tooling, strip feed, and part quality continuously.

8. Part Unloading: Collect formed parts downstream using lift table or conveyor. Stack and inspect quality.

9. Tooling Changeover: For new part profiles, change top and bottom roll sets per manufacturing sequence plan.

Safety, preventive maintenance, and following SOPs are critical for roll forming operations.

Maintenance of Keel Roll Forming Machines

Regular maintenance improves productivity and extends service life of keel roll forming machines. Key maintenance activities include:


  • Visual inspection of machine condition
  • Verify proper lubrication on all moving parts
  • Check tooling condition and wear
  • Inspect electrical, controls, and hydraulics
  • Monitor vibration, temperature, noise
  • Cleanup accumulation of dirt, debris, metal fines


  • Check anchor bolt torques
  • Check chain/gearbox backlash
  • Verify hydraulic hose/cylinder condition
  • Lubricate machine per schedule
  • Validate machine alignments


  • Complete machine inspection and service
  • Replace worn components like shafts, bearings, sprockets
  • Hydraulic system service
  • Reapply corrosion protective coatings
  • Update control software and electronics

Roll forming machines generate fines and debris. Regular cleaning and preventing accumulation is important. Properly anchoring machines, maintaining alignments, and preventing vibrations also helps extend longevity.

Choosing a Keel Roll Forming Machine Supplier

Choosing the right keel roll forming machine supplier is critical for getting capable and reliable equipment. Key selection criteria include:

Техническая экспертиза

  • Extensive knowledge of roll forming process and machines
  • Engineering staff capable of designing optimal solutions
  • Experience implementing similar projects

Manufacturing Quality

  • Modern and capable machinery to fabricate roll forming lines
  • Stringent quality control procedures
  • Reliable components sourced from reputable vendors

Возможность персонализации

  • Offer both standard and custom engineered solutions
  • Flexibility to modify and optimize designs to requirements
  • Integration of peripherals like decoilers, feeders, stackers

Commissioning and Support

  • Complete on-site commissioning and operator training
  • Responsive after-sales technical support and service
  • Local technicians for quick troubleshooting and repairs

Financial Stability

  • Financially sound company with sustainable business
  • Able to provide warranties and performance guarantees

Evaluating sample products, site visits, and customer references are also valuable in picking the right partner. Consider long-term vendor relationship for ongoing support.

Keel Roll Forming Machine Comparison

Advancements in Keel Roll Forming Technology

Recent advancements that have enhanced keel roll forming machines include:

  • Servo-electric drives for precision speed and tension control
  • Programmable controls for fast recipe and tooling changeovers
  • Автоматическая смазка systems for consistent lubrication
  • Quick-change tooling systems to reduce setup times
  • In-line part cutting for finished cut-to-length parts
  • Integrated forming and welding for hybrid C-U channel production
  • Robotic part handling for automated load/unload
  • Vision systems for quality inspection feedback
  • IoT connectivity for remote monitoring and diagnostics

These technologies enable agile and high-quality manufacturing with keel roll forming lines. Companies invest in upgrading equipment with such features to maximize productivity and competitiveness.

Pros and Cons of Keel Roll Forming vs. Alternatives

Compared to press braking, key advantages of keel roll forming machines are:

  • Higher production speeds and volumes
  • Снижение эксплуатационных расходов
  • Consistent quality along the length
  • Возможность формирования сложных и нестандартных форм
  • Lower tooling costs

Limitations are:

  • Более высокие первоначальные капитальные вложения
  • Require separate cutting process
  • Size limitations of roll forming lines

Compared to laser cutting, roll forming advantages include:

  • Lower equipment cost
  • No heat affected zones or finishing needed
  • Higher production rates for long length parts
  • Снижение эксплуатационных расходов

Disadvantages are:

  • Limited in complexity of shapes vs laser cutting
  • Typically require secondary cutting process
  • More floor space needed

Overall, keel roll forming provides lean and agile production for high-volume sheet metal channels and profiles.

Cost Saving Benefits of Keel Roll Forming

Ключ cost savings with keel roll forming machines:

  • Labor: Automated material handling reduces labor
  • Tooling: Roll dies last longer than press brakes
  • Качество: Consistent quality improves yields
  • Speed: Higher production rates improve productivity
  • Space: Compact lines maximize facility utilization
  • Безопасность: Reduced handling minimizes accidents
  • Energy: Higher efficiency lowers power costs

With its continuous production method, roll forming is often a lower cost manufacturing process compared to alternative approaches.

станок для формирования килевых валков
Uses of Keel Roll Forming Machines 6

Часто задаваемые вопросы

What is keel roll forming used for?

Keel roll forming machines are used to form C-shaped and U-shaped structural steel channels from sheet metal coils. Common applications are building construction, automotive chassis, and manufacturing equipment frames.

Какой толщины сталь может быть подвергнута прокатке?

Keel roll forming machines can typically process steel sheet thickness ranging from 0.5 mm to 3 mm. The maximum thickness depends on the machine’s rolling power and material strength.

What shapes can be formed by keel roll forming?

In addition to C and U channels, these machines can produce complex profiles like furring channels, angles, tubes, rails, panels and open girts. Custom tooling allows flexibility in shapes.

How does keel roll forming work?

It works by passing sheet metal strip through a series of roller dies to gradually shape the material. The rollers bend the flat strip into the desired contour profile based on the roller geometry.

What are the components of a keel roll forming machine?

Main components are decoiler, feeder, pre-cut shear, roller stations, driving system, guide rails, PLC control, and exit tables. High-end systems also integrate punching, welding, and cutting processes.

What is the production rate of keel roll forming machines?

Production speed ranges from 10 to 120 meters per minute depending on part complexity. Typical speeds are 50-80 m/min for common C and U channel forming applications.

How to maintain keel roll forming equipment?

Key maintenance involves lubricating rollers, inspecting tooling wear, checking alignments, changing hydraulic fluids, servicing motors/drives, and cleaning dust/debris. Periodic preventive maintenance improves productivity.

What safety is required for roll forming operations?

Machine guarding, E-stops, safety mats, electrical interlocks, and PPE like gloves/eyewear should be used. Proper material handling and stackout practices are also important. Lockout procedures must be followed during maintenance.

How much does a keel roll forming machine cost?

Cost ranges from $30,000 for basic machines to over $250,000 for large high-end production lines. Price depends on speed, size, automation features, and customization. Used machines are also available.

What factors affect keel roll forming productivity?

Key factors are line speed, setup time, material handling, tooling changeover, maintenance, line downtime, and operating practices. Modernizing equipment and training also improves productivity.

This covers the key aspects of keel roll forming machines. To summarize, it is an efficient technology for high-volume production of structural steel channels and profiles across various industries. With proper machine selection, installation, operation, and maintenance, manufacturers can benefit from lean and agile roll forming production.

узнать больше Вальцевание

Поделиться этой записью:


Поделиться этой страницей

Новое обновление

Стратируйте наш бизнес сейчас

Свяжитесь с Sunway

На ключ

Похожие сообщения

машина для формовки металлических шпилек и направляющих

Metal Stud and Track Roll Forming Machines

Metal stud and track roll forming lines efficiently transform coiled steel into C-shaped channel profile framing studs paired with U-shaped track elements used extensively constructing

mobile roll forming machine

Mobile Roll Forming Machines

mobile roll forming machine delivers lightweight fabrication capabilities onsite converting sheet coils or blanks into various structural framing, roofing, fencing, architectural panel profiles facilitating rapid

double layer roofing sheet roll forming machine

Corrugated Iron Sheet Roll Forming Machines

Corrugated iron sheet roll forming machines efficiently transform metal coil stock into roofing panels featuring a distinctive waved pattern used extensively across industrial and residential

Свяжитесь с Sunway

Последняя цена и каталог
